Specification Sheet
ARMEX Agri
Multiflow
HF1536
High-Frequency Agricultural Screening
Maize • Soya • Sunflower • And More
Clean. Size. Separate.
50–85t/h
Typical Throughput*
5.4m²
Main Screening Area
3-way
Material Separation
*Throughput is application dependent — see Performance.
Product Overview

The ARMEX Agri Multiflow HF1536 is a high-frequency agricultural screening and cleaning plant designed for efficient cleaning, sizing and separation of agricultural products including maize, soya beans and sunflower seed.

Combining a large 1 500 × 3 600 mm high-frequency screening deck with an integrated pre-cleaner, adjustable screening angle and dedicated discharge system, the HF1536 provides an efficient solution for commercial agricultural screening applications.

The plant separates material into three individual fractions, while interchangeable screen configurations allow the machine to be adapted for different crops and grading requirements.

Available in mobile wheeled or stationary configurations, with an optional PTO alternator for applications where three-phase electricity is not readily available.

Key Benefits
Why the HF1536
🔀
Three-Way Separation
Integrated pre-cleaner plus top and bottom deck products — three separate fractions from a single screening process.
⚡
High-Frequency Screening
Large 1 500 × 3 600 mm main deck with 5.4 m² screening area and adjustable vibration intensity for high-capacity screening.
🌾
Crop-Specific Screen Sets
Interchangeable screen configurations for maize, soya beans, sunflower and more — additional screen sets can be supplied to suit the crop, product and required separation.
🎛️
Hydraulic Angle Adjustment
Hydraulically adjustable screen angle to fine-tune separation for different crops and grading requirements.
🚜
PTO Power Option
Optional PTO-driven alternator for farms and fields where three-phase electricity is not readily available.
🚚
Mobile or Stationary
Wheeled chassis to move between farms, fields and processing locations, or a stationary configuration for permanent installations.
Three-Way Material Separation
Three Fractions.
One Pass.

The Agri Multiflow HF1536 is designed to produce three separate material fractions during a single screening process:

01
Pre-Cleaner Fraction
Material separated by the integrated pre-cleaner.
02
Top Deck Product
Material discharged from the upper screening section.
03
Bottom Deck Product
Material separated through the lower screening section.

This configuration provides effective cleaning, sizing and separation within a single compact plant.

Crop Applications
Screen Configurations
Maize
5–7mm
Standard screen configurations available in the 5–7 mm range.
Soya Beans
4.75mm
Typical screen configuration: 4.75 mm.
Sunflower
1.8–2.5mm
Standard screen configurations available in the 1.8–2.5 mm range.
And More
Customscreen sets
Additional screen configurations can be supplied according to the crop, product and required separation.
Performance
Typical Throughput
50–85tonnes / hour*
Typical throughput

The HF1536 has been developed for high-capacity agricultural screening while maintaining a compact and transportable machine configuration.

*Actual throughput is application dependent and may vary according to crop or material type, moisture content, bulk density, feed condition, screen aperture, required separation and operating conditions.

Technical Specifications
Agri Multiflow HF1536
Screening
Main Screen Deck1 500 × 3 600 mm
Main Screening Area5.4 m²
Pre-Cleaner1 480 × 1 600 mm
Screening SystemHigh-frequency, adjustable vibration
Screen AngleHydraulically adjustable
Product Fractions3
Performance
Typical Throughput*50–85 tonnes/hour
*Actual throughput is application dependent and may vary according to crop or material type, moisture content, bulk density, feed condition, screen aperture, required separation and operating conditions.
Discharge
Rear Main Auger300 mm diameter
Rear AugerHydraulic folding with swivel table
Bottom DischargeAuger with swivel table
Discharge ChuteIncluded
Power
Electrical Supply380 V, 3-phase
Total Installed PowerApprox. 12–15 kW
Electrical ControlsComplete control panel
Alternative PowerOptional PTO alternator
Chassis & Access
Chassis OptionsWheeled or stationary
Levelling5 manual levelling jacks
Operator AccessWalkway
Transport Dimensions
Transport Length5.9 m
Transport Width2.5 m
Transport Height2.9 m
Key Features
Machine Features
High-frequency screening technology
1 500 × 3 600 mm main screening deck
5.4 m² main screening area
1 480 × 1 600 mm integrated pre-cleaner
Adjustable vibration intensity
Hydraulic screen angle adjustment
Three separate material fractions
Interchangeable crop-specific screen sets
Integrated bottom discharge auger
300 mm rear main discharge auger
Swivel discharge tables
Hydraulically folding rear auger
Operator walkway
Discharge chute
Complete electrical control panel
Five manual levelling jacks
Wheeled or stationary configurations available
Optional PTO alternator
Power & Chassis Options
Choose Your Setup
380 V Electric

The standard machine is configured for 380 V three-phase electrical supply and is supplied complete with its electrical control panel.

Optional PTO Alternator

For agricultural applications where three-phase electricity is not readily available, the HF1536 can be supplied with an optional PTO-driven alternator, allowing operation using a suitable tractor PTO.

Wheeled Chassis

Designed for applications where the plant needs to be moved between farms, fields or processing locations.

Stationary

A stationary configuration is available for permanent or semi-permanent agricultural processing installations.

ARMEX
Clean. Size. Separate.
Tell us your crop and required separation — we will recommend the right screen set.
sales@armexequipment.com +27 71 899 0018 www.armexequipment.com

All reasonable steps have been taken to ensure the accuracy of this publication. Due to Armex Equipment's policy of continual product development, we reserve the right to make changes to specifications without prior notice or obligation. All capacities and feed sizes are provided as application aids only. No warranties are expressed or implied. All dimensions in mm unless stated. Images are illustrative renders and may show optional equipment.
